H510 Motherboard

Warranty : 3 Years

Features :

• Design LGA Socket 1200. 10/11 i3/5/7/9 Support Dual Channel DDR4 2133/2400/2666/2933/3200 Support Realtek® RTL8111E 4x SATA 3.0 1 x M2_SSD(2242/2280) NVME(PCIe x 4) 4 x USB 3.0 6 x USB 2.0

Technical Specifications :

• Processor Support: System Intel 10th/11th Generation Core Processor (Comet Lake-S/ Rocket Lake-S LGA1200) Chipset: Intel® H510 Chipset Memory Support: 2*Dual Channel DDR4 2400/2666/3200 DIMMs, up to 64GB LAN: Realtek® RTL8111E 1000 Mbps Audio: Realtek® 887 6-channel HD audio Storage: 3/4/5 * SATA3.0

• 2 * M.2 slot (PCIE x4 / SATA 6.0 Gb/s),

• Support 2260/2280 SSD USB: 4 * USB 3.0 port

• (2 at back panel, blue, 2 at mid-board)

• 6 * USB 2.0 port

• (4 at back panel, black, 2 at mid-board)Back panel: 1 * PS2 MS/KB

• 1 * HDMI 1 * VGA

• 2 * USB 3.2 Gen 4 * USB 2.0

• 1 * RJ45 LAN 1 * 6-CH AudioOn-Board Pinheaders / Connectors: 1 * USB 2.0 headers 1 * USB 3.2 Gen header

• 1 * COM header 1 * ESPI header

• 1* F_Audio header 1 * F_Panel header

• 1 * CLR_CMOS header

• 1 * 24 Pin ATX power Connector

• 1 * 8 Pin ATX power ConnectorSlots: 1 * PCI-E x16 slot

• 1 * PCI-E x1 slotsForm Factor: Micro-ATX (22cm X 17.9 cm) 6 mounting holes"
